TYPE 型號 |
CONDUCTOR(導體) | INSULATION(絕緣) |
JACKET THICKNESS 外被厚度 (mm) |
DIAMETER(外徑) | |||
|
Area 截面積(m㎡) |
NO./mm 線數/線徑 |
EP THICKNESS(mm) (厚度) |
OTHER THICKNESS(mm) (厚度) |
EP 絕緣體材質 |
OTHER 其它絕緣體材質 |
||
|
HFF HRF |
0.75/2C | 30/0.18 | 0.8 | 0.8 | 0.35 | 7.7 | 7.7 |
| 1.25/2C | 50/0.18 | 0.8 | 0.35 | 8.5 | 8.5 | ||
| 2.00/2C | 37/0.26 | 0.8 | 0.35 | 9.1 | 9.1 | ||
| 3.50/2C | 45/0.32 | 1.1 | 0.35 | 10.5 | 11.5 | ||
| 5.50/2C | 70/0.32 | 1.0 | 1.1 | 0.35 | 12.5 | 12.5 | |
| 0.75/3G | 30/0.18 | 0.8 | 0.8 | 0.35 | 8.3 | 8.3 | |
| 1.25/3G | 50/0.18 | 0.8 | 0.35 | 9.1 | 9.1 | ||
| 2.00/3G | 37/0.26 | 0.8 | 0.35 | 9.8 | 9.8 | ||
| 3.50/3G | 45/0.32 | 1.1 | 0.35 | 11.0 | 12.5 | ||
| 5.50/3G | 70/0.32 | 1.0 | 1.1 | 0.35 | 13.0 | 13.5 | |
| 0.75/4G | 30/0.18 | 0.8 | 0.8 | 0.35 | 9.2 | 9.2 | |
| 1.25/4G | 50/0.18 | 0.8 | 0.35 | 10.5 | 10.5 | ||
| 2.00/4G | 37/0.26 | 0.8 | 0.35 | 11.0 | 11.0 | ||
| 3.50/4G | 45/0.32 | 1.1 | 0.35 | 12.0 | 13.5 | ||
| 5.50/4G | 70/0.32 | 1.0 | 1.1 | 0.35 | 14.5 | 15.0 | |
