TYPE 型號 |
CONDUCTOR(導體) |
INSULATION THICKNESS 絕緣厚度 (mm) |
JACKETTHICKNESS 外被厚度 (mm) |
OVERALL DIAMETER 完成外徑(mm) |
|
|
SIZE 規格 |
NO/mm 線數/線徑 |
||||
|
HSJ HSJO HSJO0 |
18AWG/2C | 41/0.160 | 0.76 | 0.76 | 7.10±0.15 |
| 16AWG/2C | 65/0.160 | 0.76 | 7.70±0.15 | ||
| 14AWG/2C | 41/0.254 | 1.14 | 10.0±0.15 | ||
| 12AWG/2C | 65/0.254 | 1.14 | 10.9±0.15 | ||
| 18AWG/3G | 41/0.160 | 0.76 | 7.50±0.15 | ||
| 16AWG/3G | 65/0.160 | 0.76 | 8.20±0.15 | ||
| 14AWG/3G | 41/0.254 | 1.14 | 10.70±0.15 | ||
| 12AWG/3G | 65/0.254 | 1.14 | 11.7±0.20 | ||
| 18AWG/4G | 41/0.160 | 0.76 | 8.20±0.15 | ||
| 16AWG/4G | 65/0.160 | 0.76 | 9.00±0.15 | ||
| 14AWG/4G | 41/0.254 | 1.14 | 11.7±0.20 | ||
| 12AWG/4G | 65/0.254 | 1.14 | 12.9±0.20 | ||
| NOTE: Numeber of circuit conductors 2,3, or 4, AWG size of circuit conductors 18-12. | |||||
