Type 型号 |
Specification 规格 |
Conductor Construction 导体结构 No./(mm) |
Insulation thickness 绝缘厚度(mm) |
Overall diameter 完成外径(mm) |
Max Conductor resistance at 20℃ 20℃时导体电阻最大值Ω/km |
||
| No.of core线规 | AWG线规 | Bare | Tinned | ||||
| SPT-1 | 2 | 18 | 41/0.160 | 0.76 | 2.8±0.1x5.6±0.2 | 22.4 | 23.6 |
| 3 | 18 | 41/0.160 | 0.76 | 2.8±0.1x8.0±0.2 | 22.4 | 23.6 | |
| SPT-2 | 2 | 18 | 41/0.160 | 1.14 | 3.5±0.1x7.0±0.2 | 22.4 | 23.6 |
| 16 | 65/0.160 | 1.14 | 3.8±0.1x7.4±0.2 | 14.1 | 14.9 | ||
| 3(7) | 18 | 41/0.160 | 1.14 | 3.5±0.1x9.0±0.2 | 22.4 | 23.6 | |
| 16 | 65/0.160 | 1.14 | 3.8±0.1x10.0±0.2 | 14.1 | 14.9 | ||
| 3() | 18 | 41/0.160 | 1.14 | 3.5±0.1x10.1±0.2 | 22.4 | 23.6 | |
| 16 | 65/0.160 | 1.14 | 3.8±0.1x11.0±0.2 | 14.1 | 14.9 | ||
| SPT-3 | 2 | 18 | 41/0.160 | 1.52 | 4.4±0.1x8.7±0.2 | 22.4 | 23.6 |
| 16 | 65/0.160 | 1.52 | 4.7±0.1x9.5±0.2 | 14.1 | 14.9 | ||
| 14 | 41/0.254 | 2.03 | 6.0±0.2x12.0±0.3 | 8.88 | 9.34 | ||
| 12 | 65/0.254 | 2.41 | 7.5±0.2x14.0±0.3 | 5.58 | 5.88 | ||
| 3 | 18 | 41/0.160 | 1.52 | 4.4±0.1x10.8±0.2 | 22.4 | 23.6 | |
| 16 | 65/0.160 | 1.52 | 4.7±0.1x12.0±0.3 | 14.1 | 14.9 | ||
| 14 | 41/0.254 | 2.03 | 6.0±0.2x14.5±0.3 | 8.88 | 9.34 | ||
| 12 | 65/0.254 | 2.41 | 7.5±0.2x16.0±0.3 | 5.58 | 5.88 | ||
