SJT SJTW SJTO SJTOW SJTOO SJTOOW SJT-R SJTW-R

Writer： admin Time：2023-12-10 09:06 Browse：℃

Standard:UL62 CSA-C22.2

No.of conductor 导体芯数	Conductor 导体		Insulation thickness 绝缘厚度(mm)	Sheath thickness 护套厚度(mm)	Overall diameter 完成外径(mm)	Max Conductor resistance at 20℃ 20℃时导体电阻最大值Ω/km
	AWG线规	Construction 结构(NO./mm)				Bare	Tinned
2	18	41/0.160	0.76	0.76	7.5±0.2	22.4	23.6
	16	65/0.160	0.76	0.76	8.1±0.2	14.1	14.9
	14	41/0.254	0.76	0.76	8.8±0.2	8.88	9.34
	12	65/0.254	0.76	1.14	10.8±0.3	5.58	5.88
	10	104/0.254	1.14	1.52	14.6±0.3	3.51	3.70
3	18	41/0.160	0.76	0.76	7.9±0.2	22.4	23.6
	16	65/0.160	0.76	0.76	8.6±0.2	14.1	14.9
	14	41/0.254	0.76	0.76	9.4±0.2	8.88	9.34
	12	65/0.254	0.76	1.14	11.2±0.3	5.58	5.88
	10	104/0.254	1.14	1.52	15.4±0.3	3.51	3.70
4	18	41/0.160	0.76	0.76	8.6±0.2	22.4	23.6
	16	65/0.160	0.76	0.76	9.2±0.2	14.1	14.9
	14	41/0.254	0.76	0.76	10.3±0.2	8.88	9.34
	12	65/0.254	0.76	1.14	12.3±0.3	5.58	5.88
	10	104/0.254	1.14	1.52	16.9±0.4	3.51	3.70
5	18	41/0.160	0.76	0.76	9.4±0.2	22.4	23.6
	16	65/0.160	0.76	0.76	10.3±0.2	14.1	14.9
	14	41/0.254	0.76	0.76	11.4±0.2	8.88	9.34
	12	65/0.254	0.76	1.14	13.6±0.4	5.58	5.88
	10	104/0.254	1.14	1.52	19.5±0.4	3.51	3.70
