No.of conductor 导体芯数 |
Conductor导体 |
Insulation thickness 绝缘厚度 (mm) |
Overall diameter 完成外径 (mm) |
Max Conductor resistance at 20℃ 20℃时导体电阻最大值Ω/km |
||
|
Normal area 标称面积(m㎡) |
Construction 结构(NO./mm) |
|||||
| Bare | Tinned | |||||
| 2 | 0.75 | 43/0.15 | 0.8 |
6.60±0.4 .60±0.4 |
26.0 | 26.7 |
| 1.0 | 57/0.15 | 0.8 |
6.90±0.4 6.90±0.4 |
19.5 | 20.0 | |
| 1.5 | 85/0.15 | 0.8 | 7.40±0.4 | 13.3 | 13.7 | |
| 3 | 0.75 | 43/0.15 | 0.8 |
7.00±0.4 7.00±0.4 |
26.0 | 26.7 |
| 1.0 | 57/0.15 | 0.8 | 7.40±0.4 | 19.5 | 20.0 | |
| 1.5 | 85/0.15 | 0.8 | 7.90±0.4 | 13.3 | 13.7 | |
